VWK-55-5000

Vacuum exchange fixture

The VWK-55-5000 is a vacuum changing system with maximum flexibility.

The contact is made mechanically and the cassette can be changed easily. It can be equipped with any type of external interface and can therefore be connected to all types of test systems.

•     Contact force: 1500 N and more
•     External dimensions: 600x440x140 mm
•     Usable area: 320x220 mm
•     Weight: 10kg
•     Parallel stroke: 13 mm
•     Type of test / application: ICT, FCT

Internal interface: Pylon 2x 360 test points
desk case
PAG locking system
Rounded sealing corners
ESD compatible plate material
Suitable for 1-level and 2-level contacting
Internal handovers

Passende Vakuum-/Vakuumschwenkhauben separat erhältlich

• VH-101

Product line includes

• VWK-55-5000-P
